model number
|
YFL-G-DC007A
|
|
sports event
|
parameters
|
Electrical Specifications
|
wiring method
|
L、N、PE
|
|
input voltage range
|
single phase input 90VAC to 265VAC
|
|
maximum Input Current
|
32A
|
|
frequency
|
47Hz-63Hz
|
|
maximum output power
|
7kW,constant power above 350V
|
|
maximum output current
|
20A
|
|
output voltage adjustable range
|
100VDC ～ 750VDC
|
|
output leakage current action value
|
<3.5mA@264VAC
|
|
output power factor
|
≥0.99@220VAC 50-100% Load
|
|
Operating environment
|
operating temperature
|
-20℃至55℃
|
|
humidity level
|
93% maximum (relative humidity)
|
|
height above sea level
|
≤2000m
|
|
IP rating
|
Ip54
|
|
Cooling method
|
Forced air cooling
|
|
Mechanism specifications
|
Product Size
|
380*490*158mm
|
|
Shell material
|
sheet metal
|
|
Net weight of equipment
|
≤18KG (with gun)
|
output gun line
|
5M 9-hole DC gun
|
|
noises
|
≤60dB(A)
|
|
Protection mechanisms
|
input measurement
|
Under-voltage, over-voltage, leakage protection, over-temperature protection
|
|
output measurement
|
Over-current, over-voltage, abnormal draw protection
|
|
internally
|
Over Temperature, MCU Function Error Detection
|
|
Status display
|
status indicator
|
LED running light
|
|
monitor
|
4.3” OLED
|
|
Communication standard
|
Plug and play (standard), card charging (optional), 4G (optional), LEN (optional)
|
