category |
name |
parameter |
|
|
ambient condition |
operation temperature |
-40C~+75℃; -40℃module startup; Reduced usage above 60 ℃; Shutdown above 75 ℃ |
|
|
Over Temperature Protection |
Inlet temperature>75 ℃ or<40 ℃,Module shutdown protection |
||
|
Storage temperature |
40℃~85℃ |
||
|
Working humidity |
≤95%，No condensation |
||
|
altitude |
Altitude<2000m; For distances over 2000m, consideration should be given to reducing the usage limit |
||
|
Communication input |
INPUT VOLTAGE |
260~485VAC; Rated voltage 380VAC ± 15%;
|
|
|
input frequency |
55Hz±10Hz |
||
|
THD |
≤5%(50% rated power~100% rated power) |
||
|
Number of phases |
Three phase+protective ground |
||
|
Power Factor Correction |
≥0.95(20% rated power~50% rated power)； ≥0.98(50% rated power~100% rated power) |
||
|
Input standard current |
＜76A |
||
|
Under voltage protect |
255±5VAC,return difference≥15VAC |
||
|
Over voltage protect |
490±5VAC,return difference≥15VAC |
||
|
Input power limit |
When the input voltage is between 260 ± 5VAC and 320 ± 5VAC, the output power increases linearly from 50% |
||
|
DC Output |
Output rated value |
1000VDC/40A |
|
|
Constant power range |
40kW |
low voltage mode: 300VDC~500VDC High voltage mode：500VDC~1000VDC |
|
|
Output voltage range |
150VDC~1000VDC |
||
|
Current range |
0~133.3A |
||
|
Output overvoltage protection |
1010±10VDC |
||
|
Output undervoltage alarm |
140±5VDC |
||
|
Short circuit protection |
Short circuit automatic shutdown protection, after the fault is eliminated, a power on command needs to be issued |
||
|
Output voltage ripple factor (25C) |
≤1%（500VDC~1000VDC） |
≤1%（200VDC~500VDC） |
|
|
Voltage stabilization accuracy |
≤±0.5% |
||
|
Steady flow accuracy |
≤±1% |
||
|
Output voltage setting error |
≤±0.5% |
||
|
Output current setting error |
≤±0.3A(set output DC current < 30A); |
||
|
Accuracy of current sharing |
≤±5%(current limit, 50%~100% rated) |
||
|
Boot overshoot amplitude |
≤±4% |
||
|
Normal startup time |
3S≤t≤8S |
||
|
efficiency |
Rated efficiency ≥96%, maximum efficiency ≥97% |
||
|
Physical characteristics |
noise |
noiseless |
|
|
Cooling mode |
Liquid cooling |
||
|
Overall dimension |
Height: 120mm*300mm*460mm(width * height * depth)
|
||
|
Quality |
≤28kg |
||
|
MTBF |
400000小时（40℃) |
||
