| Model number | YFL-ET10000A |
| Battery type | Lithium-ion battery |
| Rated battery voltage (V) | 500 |
| Battery Voltage Range (V) | 180-600 |
| Maximum continuous charging current (A) | 25 |
| Maximum continuous discharge current (A) | 25 |
| Maximum charging power (W) | 10,000 |
| Maximum discharge power (W) | 10,000 |
| Rated output voltage (V) | 400/380 |
| Output voltage Frequency (Hz) | 50/60 |
| Rated output current (A) | 16.5 |
| Power factor | 1 (0.8 lead... 0.8 Adjustable lag) |
| Total current waveform distortion rate | <3% |
| Maximum efficiency | 98.20% |
| Operating temperature range (℃) | ‘-35-60℃ |
| Relative humidity | 0～95% |
| Maximum working altitude (m) | 4000 |
| Cooling mode | Natural cooling |
| Cooling mode | LED,LCD, APP |
| BMS communication mode | RS485, CAN |
| Electric meter communication mode | RS485 |
| Weight (kg) | 24 |
| Dimensions (width × height × thickness mm) | 415×516×180 |
| Noise (dB) | <30 |
| Topological structure | Non-isolated type |
| Night power Consumption (W) | <15 |
| Grid type | Three phase |
| Installation mode | Wall mounting |
| Environmental grade | 4K4H |
| Class of protection | IP66 |
| Grid connection standard | VDE-AR-N 4105, VDE 0126-1-1, EN 50549-1, G98, G99, G100, CEI 0- 21 |
| Safety standard | IEC62109-1&2 |
| Safe service life (years) | ≥ 25 |
