| Model number | YFL-ES6000A |
| Battery type | Lithium-ion battery |
| Rated battery voltage (V) | 48 |
| Battery Voltage Range (V) | 40-60 |
| Maximum continuous charging current (A) | 120 |
| Maximum continuous discharge current (A) | 120 |
| Maximum charging power (W) | 6,000 |
| Maximum discharge power (W) | 6,300 |
| Rated output voltage (V) | 170/280 |
| Output voltage Frequency (Hz) | 50/60 |
| Rated output current (A) | 26.1 |
| Power factor | 1 (0.8 lead... 0.8 Adjustable lag) |
| Total current waveform distortion rate | <3% |
| Maximum efficiency | 97.60% |
| Operating temperature range (℃) | ’-25-60℃ |
| Relative humidity | 0～95% |
| Maximum working altitude (m) | 000 (>2000 Derated) |
| Cooling mode | Natural cooling |
| Cooling mode | LED |
| BMS communication mode | CAN |
| Electric meter communication mode | RS485 |
| Weight (kg) | 21.5 |
| Dimensions (width × height × thickness mm) | 505.9×434.9×154. |
| Noise (dB) | <30 |
| Topological structure | Isolated type |
| Night power Consumption (W) | <10 |
| Grid type | monophase |
| Installation mode | Wall mounting |
| Environmental grade | 4K4H |
| Class of protection | IP65 |
| Grid connection standard | AS4777.2-2020； NRS 097-2-1； CEI 0-21 |
| Safety standard | IEC62109-1&2 |
| Safe service life (years) | ≥ 25 |
